6-Port Clear Multi-Tap Pre-Insulated Connector, 3/0 – 6 AWG

#IPLD3/0-6C

Polaris Vision Tap Multi-Tap Connectors form secure connections between multiple conductors with a transparent rounded design and chemical-resistant insulation coating. Installs with a hex key and torque wrench, with no need for cover and taping.

  • Clear Exterior: Vision Tap transparent design lets users see their work to ensure ideal conductor placement and the most secure connection. Suitable for use on the line side of the service equipment as per the NEC article 230.46 requirement.
  • Dual-Sided Wire Entry: Form secure connections between 6 conductors quickly using the double-side entry ports sized for wires between 3/0 and 6 AWG
  • Ergonomic Design: Rounded corners and a smooth exterior finish over the abrasion-resistant plastisol insulation make Polaris connectors comfortable to grip
  • Removable Plugs: Each port and set screw comes with a secure plug to prevent debris from entering the insulated connector
  • Pre-filled Oxide Inhibitor: All 6 dual-sided entry (DSE) ports come pre-filled with an oxide inhibitor gel to prevent corrosion and provide low-contact resistance

Product Information

Voltage Rating 600 V
Material Aluminum
Finish Plastisol Insulated
Color Clear
UPC 662381997012
Origin Country US
Certifications cULus, 9d71e7f821454f7b84f0a15642ea01d2
Ul Standard UL 486A/B
Ul File No E186991
Wire Cable Class Class B, Class C
Al Conductor Max Amp 175
Cu Conductor Max Amp 225
Conductor Cu Size Range 3/0 AWG – 6 AWG
Conductor Al Size Range 3/0 AWG – 6 AWG
Conductor Type Copper, Aluminum
Temp Rating 90C, AL9CU
Conductors Count 6
Hex Wrench Size 1/4
Env Temp Cold Temperature rated to -45C
Assortment Clear Coated Pre-Insulated Connectors
Max Torque 250
