4-Port Grey Multi-Tap Pre-Insulated Connector, 3/0 – 4 AWG

#IPLG3/0-4

Polaris Grey Multi-Tap Connectors form secure connections between multiple fine-stranded wire conductors, with a rounded design and UV-resistant insulation coating. Installs with a hex key and torque wrench, no need for cover and taping.

  • One-Side Wire Entry: Form secure connections between 4 conductors quickly using the single-side entry ports sized for wires between 3/0 and 4 AWG
  • Fine-Stranded Wires: Specially designed to splice fine-stranded, flexible and extra-flexible copper conductors, including DLO cable and motor lead wires
  • Ergonomic Design: Rounded corners and a smooth exterior finish over the plastisol insulation make Polaris connectors comfortable to grip
  • Removable Plugs: Each port and adjustable set screw is covered by a secure plug to prevent debris, moisture or contaminants from entering the insulated connector
  • Tightening Ferrule: The pre-installed tin-plated copper ferrule in each port collapses against fine strands to prevent tearing from the rotation of the screw

Product Information

Voltage Rating 600 V
Material Aluminum
Finish Plastisol Insulated
Color Black with Grey Caps
GTIN 662381951564
UPC 662381951564
EAN 662381951564
UNSPSC 39121409
Origin Country US
Certifications cULus
Ul Standard UL 486A/B
Cu Conductor Max Amp 225
Conductor Cu Size Range 3/0-4 AWG (CLASS B, C,D) & 2/0-2 AWG (Classes G, H, I, K, M, DLO)
Conductor Type Copper
Temp Rating 90C, 9CU
Conductors Count 4
Hex Wrench Size 3
Env Temp Cold Temperature rated to -45C
Assortment Fine Stranded Wire Pre-Insulated Connectors
Application Splice, Tap
Max Torque 250
