2-Port Clear Multi-Tap Pre-Insulated Connector, 250 MCM – 6 AWG

#IT-250C

Polaris Vision Tap Multi-Tap Connectors form secure connections between multiple conductors with a transparent rounded design and UV-resistant insulation coating. Installs with a hex key and torque wrench, with no need for cover and taping.

  • Clear Exterior: Vision Tap transparent design lets users see their work to ensure ideal conductor placement and the most secure connection
  • Dual-Side Wire Entry: Form secure connections between 2 conductors quickly using the double-sided entry ports sized for wires between 250 MCM and 6 AWG
  • Ergonomic Design: Rounded corners and a smooth exterior finish over the plastisol insulation make Polaris connectors comfortable to grip
  • Pre-filled Oxide Inhibitor: Both dual-sided entry ports are covered by removable plugs and pre-filled with an oxide inhibitor gel to protect against corrosion, debris or moisture
  • Professional Performance: The durable layer of insulation on each Polaris connector is UV, abrasion and chemical-resistant for reliable performance

Product Information

Voltage Rating 600 V
Material Aluminum
Finish Plastisol Insulated
Color Clear
Pack Qty 6
GTIN 662381996435
UPC 662381996435
EAN 662381996435
UNSPSC 39121409
Origin Country US
Certifications cULus
Ul Standard UL 486A/B
Wire Cable Class Class B, Class C
Al Conductor Max Amp 230
Cu Conductor Max Amp 290
Conductor Cu Size Range 250 MCM-6 AWG
Conductor Al Size Range 250 MCM-6 AWG
Conductor Type Copper, Aluminum
Temp Rating 90C, AL9CU
Conductors Count 2
Hex Wrench Size 5
Env Temp Cold Temperature rated to -45C
Assortment Clear Coated Pre-Insulated Connectors
Application Splice
Max Torque 360

Resources

Documents

  • PolarisBlack-VisionTap_Torque-AssemblyChart_DIGITAL.pdf Download
  • POL_BLK-VT_MCH_ProdInstall_DIGITAL.pdf Download
  • PRODRAW_ITC SERIES.pdf Download
  • POL_PREINSUL_MCH_ProdBro_DIGITAL.pdf Download
  • POL_VisionTap_MCH_ProdSheet_DIGITAL.pdf Download
